SmartBending—Inline Measurement for Process Correction

Inline process optimization for error compensation in swivel bending

Christian Donhauser ORCID Icon, Reinhard Schmied, Marco Susic
JournalIndustry 4.0 Science
Issue Volume 42, 2026, Edition 3, Pages 134-141
Bibliography Share Cite Download

Abstract

Swivel bending is an established forming process that minimizes material loss and enables efficient use of resources. However, the process requires complex optimizations that have traditionally relied heavily on the expertise of machine operators. This results in significant time and material costs, as optimization steps are performed iteratively. Given the shortage of skilled workers, a technological upgrade of the machines in line with Industry 4.0 is necessary. As part of a research project, intelligent sensor technology was used to record critical influencing factors that reveal correlations between product defects and machine deformations. Based on this, a methodology was developed that forms the foundation for inline compensation, enabling the equipment to autonomously adjust process parameters to correct product defects and, in the long term, enable defect-free production from the very first component.

Keywords

, , , , ,

Article

Due to its flexible applicability, swivel bending is a widely used process in industrial sheet metal forming [1]. At first glance, it appears to be a comparatively simple process: sheets are clamped between upper and lower beam tools and bent along a defined line using a swiveling bending beam (Figure 1) [2]. To achieve the desired bending angles with sufficient dimensional accuracy over the entire sheet length, considerable adjustment effort and experienced machine operators are required despite modern Computerized Numerical Control (CNC) systems [3, 4]. A major cause of angle deviations …
